1010-S 1" x 1" Smooth Surface T-Slotted Profile
1010-S 1" x 1" Smooth Surface T-Slotted Profile

1010-S 1" x 1" Smooth Surface T-Slotted Profile

1010-S-24
Orders ready to ship/pick up in approx 2-4 business days from Abbotsford, BC

1010-S 1" x 1" Smooth Surface T-Slotted Profile - Four Open T-Slots

1010-S is a 1.00” x 1.00” fractional 10 series square T-slot profile with four open T-slots, one on each 1.00” face. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 1010-S profile is compatible with all 10 series fasteners. The four open T-slots enable access from any direction and are useful for mounting accessories.

USA Made from 80/20 Inc

CAD Library: https://8020.net/tools-cad

Series 10 Series
Material Aluminum
Grade 6105-T5
Finish Anodize
Color Clear
Drop Lock 2°
Moment of Inertia - IX 0.0463”⁴
Moment of Inertia - IY 0.0463”⁴
Surface Area 0.437 Sq. In.
Yield Strength 35,000 psi.
Modulus of Elasticity 10,200,000 Lbs / Sq. In.
Weight lbs 0.0424
Weight 0.0424
