1003-S 1” X 1” Smooth Surface T-Slotted Profile - Three Adjacent Open T-Slots

1003-S-24
  • $7.45


Orders ready to ship/pick up in approx 2-4 business days from Abbotsford, BC

1” X 1” Smooth Surface T-Slotted Profile - Three Adjacent Open T-Slots

1003-S is a 1” x 1” fractional 10 series square T-slot profile with three adjacent open T-slots, one on three 1” faces. The profile is smooth, which makes it resistant to dirt and debris buildup while also being easy to clean. The 1003-S profile is compatible with 10 series fasteners. The closed face on this profile provide a clean, aesthetic look and lends itself to work spaces, displays or retail kiosks.

Series 10 Series
Material Aluminum
Grade 6105-T5
Finish Anodize
Color Clear
Drop Lock
Moment of Inertia - IX 0.0510”⁴
Moment of Inertia - IY 0.0463”⁴
Surface Area .461 Sq. In.
Yield Strength 35,000 psi
Modulus of Elasticity 10,200,000 Lbs / Sq. In.
Weight lbs 0.0447
Weight 0.0447
